Wet Film Humidifier

Shanghai Feizhong cabinet-type wet film humidification and purification humidifier JDH series is a pollution-free, high-clean humidification system controlled by a single-chip computer. The three-layer composite purification core purifies the air.

Power:220V-3P-50Hz
Humidification Capacity:15kg/h——80kg/h
Standard Condition:T=30°C; RH:25%
Power: 220V~50Hz
Input Power: 500W——1200W
Rated Current: 2——5.6A
Water Tank Capacity:25kg——50kg
Circulation Air Volume: 2000m3/h——8000m3/h
Applicable Area:150m2——900m2
Brand:Feizhong
Send Inquiry

Product Introduction Technical Parameter

Shanghai Feizhong cabinet-type wet film humidification and purification humidifier JDH series is a pollution-free, high-clean humidification system controlled by a single-chip computer. The three-layer composite purification core purifies the air. The clean water is continuously sent to the upper part of the wet film through the water pump, and the water is evenly distributed through the water distributor. Under the action of gravity, the water returns to the main water tank through the wet film to form a cycle. When the dry air passes through the wet film, the air and the wet film are fully Contact, the circulating wind generated by the fan vaporizes the water and increases the humidity environment, while the wet film filters the dust in the air, and the three-layer composite purification core. So as to achieve the purpose of humidification, dust removal and air purification.

Wet film humidifier JDH series is a high-quality unit that offers numerous benefits for users in various settings. One of the main advantages of this humidifier is its ability to increase the humidity levels in a room quickly and effectively. It achieves this through the use of a wet film, which constantly draws in water and releases it into the air, creating a comfortable and healthy environment.

Another noteworthy aspect of the JDH humidifier is its energy efficiency. It consumes little power, making it an ideal choice for those who are environmentally conscious. Additionally, its compact size and easy-to-use design make it a convenient option for both home and office settings.

The JDH humidifier is particularly suited for dry environments, such as those found in arid regions or during the winter months when heating systems can dry out indoor air. It is also ideal for use in hospitals and other medical facilities, as it can help maintain a healthy environment by reducing the risk of airborne infections.

Overall, the JDH humidifier stands out for its efficiency, convenience, and ability to improve the quality of the air in any environment it is placed in. Whether you need to alleviate allergies, combat dry skin, or simply want to breathe in cleaner, more comfortable air, the JDH humidifier is an excellent choice.



Features

1. Low carbon, environmental protection, energy saving, power saving, high efficiency.

2. Electronic touch buttons, more convenient to operate and use.

3. Humidity automatic control, RH196-99% arbitrary adjustment.

4. Large humidification range, uniform and clean humidification, no white powder.

5. Lack of reminder and automatic shutdown protection.

6. Turbo fan, large circulating air, high humidification efficiency.

7. Three wind speeds can be set freely, and ventilation and humidification can be switched.

8. With ventilation mode to circulate indoor air.

9. Anti-vibration and non-slip universal wheels on the soles of the feet, easy to move.

10. Use high-efficiency antibacterial materials to achieve high-efficiency sterilization, and there is no requirement for water quality.

11. Suitable for humidification in offices, bedrooms, beauty rooms, electronic warehouses and other places.

Send Inquiry

We have an advanced technical team and a professional after-sales department that can provide 24-hrs online consulting services.

We warmly welcome you to wholesale customized chiller made in China here from our factory.

Pls contact us for more details.

Hot Tags: wet film humidifier, China wet film humidifier manufacturers, suppliers, factory, industrial air ultrasonic humidifier, Electrode Type Constant Humidifier, industrial ultrasonic fogger, industrial cool mist humidifier, , Industrial Ultrasonic Humidifier

Model

JDH-06

JDH-30

JDH-60

JDH-30GZ

JDH-60GZ

Humidification Capacity

15kg/h

30kg/h

60kg/h

30-40kg/h

60-80kg/h

Standard Condition

T=30° RH:25%

T=30° RH:25%

T=30° RH:25%

T=30° RH:25%

T=30° RH:25%

Power

220V~50Hz

220V~50Hz

220V~50Hz

220V~50Hz

220V~50Hz

Input Power

500W

800W

1200W

1200W

1200W

Rated Current

2-3A

3. 88A

5. 6A

5. 6A

5.6A

Ambient Temperature

-5-40'C

-5~40'C

-5~40°C

-5-40V

-5~4(rc

Water Tank Capacity

25kg

50kg

50kg

50kg

50kg

Circulation Air Volume

2000m3/h

4000m3/h

8000m3/h

4000m3/h

8000m3/h

Water Adding Method

Connect hose for automatic water refill

Connect hose for automatic water refill

Connect hose for automatic water refill

Connect hose for automatic water refill

Connect hose for automatic water refill

Running Noise

50dB

60dB

60dB

60dB

75dB

Humidity Control Range

30-65% ±5

30-65% ±5

30-65% ±5

30-65% ±5

30-65%±5

Applicable Area

150-200m2

300~500m2

400~900m2

300~500m2

400-900m2

Dimensions mm

500X 1240X 1850

900X450X 1850

1200X500X1850

900X600X2100

1200X700X2100

Net Weight

95kg

150kg

170kg

130kg

150kg
