Precision Air Conditioner For Server Room

Precision air conditioner for data room refers to the special precision air conditioner for computer room that can fully meet the environmental conditions of the computer room. It is a new model developed in the past 30 years. Compared with the comfort air conditioner with the same cooling capacity, the special air conditioner for the computer room has a large air volume and a small enthalpy difference, which also increases the evaporation temperature of the unit, which improves the cooling efficiency and thus improves the economy of the unit. The precision air conditioner for the computer room can also simultaneously The relative humidity in the room is accurately maintained within the preset range to achieve the effect of constant temperature and humidity in the entire computer room。

Power：380V-3P-50Hz
Total Unit Power:7.5kW——48.6kW
Cooling Capacity：5.8kW——55kW
Heating Capacity: 3kW——18kW( PTC/Electric Heating Tube Type)
Humidification: 3kg/h——13kg/h(Electrode Type)
Circulation Air Volume:1500m3/h——17000m3/h
Temperature And Humidity Range：T:18-25℃,Precision±2%; RH:50-70%, Precision±5-10%
Brand:Feizhong

Send Inquiry

Product Introduction Technical Parameter

Precision Air Conditioner

Feizhong precision air conditioner adopts advanced fuzzy logic control or PID mediation technology;It has the function of large-capacity fault alarm record storage;The unit has overvoltage, undervoltage and other alarms and fault diagnosis, alarm recording functions, as well as automatic protection, automatic recovery, automatic restart and other functions;

Realize real-time monitoring of all components: accurately and clearly display any accidents and abnormal operation conditions and record the operating periods of fans, compressors, humidifiers and electric heating in real time, which is convenient for customers to repair and maintain;

Crisis management: heaters and humidifiers have simple braking procedures that can still meet basic cooling needs in preset emergency situations.

Air-conditioning units and modules can realize inter-connection and mutual monitoring without using a computer, and automatically adjust the operating status of each module, so that the unit is always in the best operating state, ensuring reliable operation of the unit and reducing operating costs.

High Efficiency And Energy Saving

Double control point logic program to avoid competitive operation;

High-efficiency scroll compressor, low-cost and efficient operation;

EC fan, high efficiency, low noise, adjustable air volume pressure head;

Rapid dehumidification control to avoid excessive start-up of electric heating;

The air channel is completely isolated, even if it is debugged and maintained, it will not affect the air supply work;

Perfect control logic ensures low-torque startup of the compressor, reducing the impact on the power grid;

The fan of the outdoor unit adopts stepless speed regulation control to achieve the best cooling efficiency.

High Reliability

The design and selection of unit equipment is higher than the industrial standard;

Hydrophilic aluminum foil heat exchanger, longer life;

Fully enclosed high-efficiency scroll compressor;

Suitable for the requirements of frequent switching cycles and long-term operation of precision air-conditioning systems;

Compressor energy efficiency ratio is high;

Low exhaust temperature, low compression ratio and high efficiency;

There is no reciprocating inertial force, and the operation process has good balance;

Anti-oxidation coating technology for all welding points, which can be used for a long time in harsh environments;

Strict selection of high-quality components;

A variety of configuration options: such as electric heating tube/PTC ceramic electric heating, electrode humidifier/infrared humidifier/film humidifier, etc.;

The metal frame G4 standard filter is adopted, and the filtering effect is good (G4 level), which can make the air in the machine room clean and dust-free; it can be washed repeatedly; and the maintenance is very convenient. It is more suitable for computer rooms with high cleanliness requirements.

Compact Size

The unit is carefully manufactured using high quality components. Small footprint, the unit can be operated and maintained from the front.

Powerful Intelligent Control System

The control system has two stages of microprocessors. After setting the parameters on the display, remove the display, and the unit will continue to work; when the air conditioner controller fails, other air conditioner controllers can be used to work without affecting the operation of the unit, which improves the reliability and guarantee of operation sex;

The network monitoring method is flexible and supports a variety of network monitoring methods. Various networking monitoring methods such as remote, short-range, and power network can be realized. The communication interface has various forms such as RS485, and an open communication protocol is provided free of charge;

Application

Medical equipment room

Precision workshop

Laboratory

Precision machine room

Send Inquiry

We have an advanced technical team and a professional after-sales department that can provide 24-hrs online consulting services.

We warmly welcome you to wholesale customized chiller made in China here from our factory.

Pls contact us for more details.

Hot Tags: precision air conditioner for server room, China precision air conditioner for server room manufacturers, suppliers, factory

Precision Type			ZYHFS5N	ZYHFS8N	ZYHFS10N	ZYHFS13N	ZYHFS20N	ZYHFS26N		ZYHFS32N	ZYHFS45N	ZYHFS55N
Cooling Capacity		kw	5.8	8.1	10.2	13.2	20.3	25.8		31.8	45	55
Heating Capacity		kw	3	5	6	6	12	12		18	18	18
Humidification		kg/h	3	3	4	4	8	8		8	8	13
Circulation Air Volume		m3/h	1500	2400	3000	3800	6000	7800		10000	13500	17000
External Static Pressure		Pa	Direct Bowing Type 30-80Pa; Pipeline Type 150-300Pa (please specify when ordering)
Return Air Mode			Front Return Air Front Outlet				Front Return Air Top Outlet
Unit Noise		dB(A)	57	62	64	64	64	65		68	70	70
Temperature And Humidity Range			T:18-25℃,Precision±2%; RH:50-70%, Precision±5-10%
Power			380V/3～50Hz,3 phase 5 wire system
Total Unit Power		kw	7.5	10.4	13	14.3	25.2	26.9		36.5	40	48.6
Refrigeration /Dehumidification	Working Medium/Throttling Mode		R22/R407C/R410a---Thermal Expansion Valve
	Compressor Type		Rotor Type--Scroll Type; Compressor Brand: Panasonic/Copeland/Invotech
	Single Unit Power	kw	1.8	2.5	3	4	5.5	7		4.5	6.2	8
	QTY	pc	1	1	1	1	1	1		2	2	2
Heating	Type		PTC/Electric Heating Tube
Heating	Power	kw	3	5	6	6	12	12		18	18	18
Humidifier	Inlet Pipe Diameter		Electrode Type; Inlet Pipe Diameter DN15
	Power	kw	2.25	2.25	3	3	6	6		6	6	9.75
	Humidification Capacity	kg/h	3	3	4	4	8	8		8	8	13
Fan	Type		EC Outer Rotor Low-Noise Double-Inlet Centrifugal Type/ EC Backward-Facing Type			EC Backward Centrifugal Fan
	Power	kw	1	1	1	1	1	1		1	1	2
	QTY	pc	0.18	0.25	0.55	0.55	1.6	1.6		1.75	1.9	1.6*2
Filter	Type		Plate Filter G4
Main Unit Size	L	mm	650	650	800	800	1260	1260		1560	1560	1700
	W	mm	575	575	645	645	800	800		850	900	1000
	H	mm	1750	1750	1950	1950	2150	2150		1980	1980	1990
Connecting Pipe	Connection Method		Bell Mouth			Welding	Bell Mouth		Welding
	Liquid Pipe	mm	9.52(1)	9.52(1)	12.7(1)	12.7(1)	15.8(1)	15.8(1)		12.7(2)	15.8(2)	15.8(1)
	Steam Pipe	mm	12.7(1)	12.7(1)	12.7(1)	12.7(1)	15.8(1)	22.2(1)		12.7(2)	15.8(2)	22.2(1)
Outdoor Unit	model (Top blown)		JFN2A	JFN3A	JFN4A	JFN5A	JFN8A	JFN10A		JFN6A	JFN8A	JFN10A
	QTY	pc	1	1	1	1	1	1		2	2	2
	Air volume	m3/h	3500	5000	6200	7000	8500	12000		8500*2	8500*2	12000*2
	Fan power	kw	0.18	0.38	0.38	0.5	0.55	0.8		0.55*2	0.55*2	0.8*2
	Dimensions	L mm	700	700	700	700	750	850		750	750	850
		W mm	700	700	700	700	750	850		750	750	850
		H mm	900	900	940	940	940	940		940	940	940

Noted

1. Unit test conditions: indoor dry bulb: 24°C, 55%; outdoor dry bulb: 35°C, wet bulb: 24°C;
2. The unit adopts cabinet-type front-return and front-feed or front-return and top-feed;
3. Facing the operation display screen of the unit, the connecting pipe is located on the left side of the unit. If the connecting pipe is required to be on the right side, please specify when ordering;
4. The number of copper pipes in the brackets of the connecting pipe;
5. The noise value is for reference only, and the specific test value will be affected by factors such as the environment;
6. The main unit is black, and the outdoor unit is milky white.
