Air Cooled Dehumidifier

Air Cooler Dehumidifier CFTZ/CFJZ series are a high-quality product developed by our company, which has the advantages of high dehumidification efficiency, low noise, energy-saving and environmental protection, and is suitable for various industrial and commercial fields.

Power: 380V-3P-50Hz
Dehumidifying Capacity:10kg/h —— 60kg/h
Refrigerating Capacity: 16.5——98kW
Air Volume: 3000——18000m³/h
Distribution Power:6.1kW——37kW
Refrigerant: R22/R410A
Brand:Feizhong
Send Inquiry

Product Introduction Technical Parameter

QQ20240412172241



Air Cooler Dehumidifier

Air Cooler Dehumidifier CFTZ/CFJZ series are a high-quality product developed by our company, which has the advantages of high dehumidification efficiency, low noise, energy-saving and environmental protection, and is suitable for various industrial and commercial fields.








Feature and Advantage





1
product-1-1

High Efficiency and Energy Saving,the evaporator is used to cool and dehumidify the air, and the condensation heat of the system is recovered to make up for the heat lost in the air due to cooling and dehumidification.

2
product-1-1

The unit fully applies modern control technology, optimizes the control model, adopts advanced PLC as the control system, is equipped with a friendly and simple full-English man-machine interface and can be customized according to user requirements.

3
product-1-1

High adjustment accuracy, adjust the heat distribution between the outdoor heat exchanger and the indoor heat exchanger, and adjust the cooling or heating capacity of the system to improve the adjustment accuracy of temperature and humidity.

4
product-1-1

The unit can be connected with a remote computer through a modem or an Ethernet module, exchange data with the Internet, and perform remote monitoring and fault analysis on the unit, helping you to predict and eliminate faults quickly and accurately.



Product Accessory

industrial dehumidifer 1

Application





1712906134471



Pharmaceutical Industry

The equipment can effectively control the humidity and temperature of the production environment, improve the quality of the products, and ensure the safety and effectiveness of the medicines.

Building Industry



Building Industry

The equipment can effectively remove the moisture from the concrete and building materials, improve the strength and durability of the buildings, and create a comfortable and healthy living environment for people.

1

Electronics industry

The equipment can maintain the stable and dry environment of the production workshop, prevent the damage of electronic components and products caused by moisture, and ensure the high reliability and performance of the products.

2

Food industry

Our temperature control dehumidifier can control the moisture content of the raw materials and products, prevent the growth of bacteria and microorganisms, and improve the shelf life and quality of the foods.

Send Inquiry

We have an advanced technical team and a professional after-sales department that can provide 24-hrs online consulting services.

We warmly welcome you to wholesale customized chiller made in China here from our factory.

Pls contact us for more details.

Hot Tags: air cooled dehumidifier, China air cooled dehumidifier manufacturers, suppliers, factory, Air conditioner cooler dehumidifier, Air Cooler Dehumidifier, Water-cooled dehumidifier, , temperature control dehumidifier

Item
Model CFTZ10 CFTZ15 CFTZ20 CFTZ25 CFTZ30 CFTZ40 CFTZ50 CFTZ60
CFJZ10 CFJZ15 CFJZ20 CFJZ25 CFJZ30 CFJZ40 CFJZ50 CFJZ60
Dehumidification capacity Kg/h 10 15 20 25 30 40 50 60
Refrigerating capacity Kw 16.5 24 31.1 40.8 49 65.4 81.6 98
Air volume m³/h 3000 4500 6000 7500 9000 12000 14000 18000
External Static Pressure Pa 0 0 0 200 250 250 250 250
250 300 300 300 300
Power 380V,50HZ; 3 Phase 4 Wire System
Distribution Power Kw 6.1 8.3 11.2 15 20 25 30 37
6 8 11

Refrigerant

Type R22/R410A
Throttling Mode External Balanced Thermal Expansion Valve
Charge Volume Kg 6 8 10 12 14 20 24 28
4 6 8 10 12 16 20 24


Indoor unit


Fan
Type Low Noise Centrifugal With Outer Rotor
Power Kw 0.55 0.37X2 0.55X2 1.0X2 1.0X2 1.5×2 2.2×2 3.0X2
0.45 0.25X2 0.37X2

Overall Dimension

L mm 960 1260 1600 1690 1850 2000 2000 2000
W mm 650 800 800 700 900 1000 1000 1050
H mm 2050 2150 2250 1925 2250 2250 2250 2250

Weight

Kg 290 310 350 400 550 700 800 1000
265 295 315 340 450 620 700 880


Outdoor unit

Compressor

Type Fully Enclosed
Power Kw 4.66 6.8 9 11.2 15 18.6 22.4 27.2

Fan
Type Low Noise Axial Flow
Air volume m³/h 8500 8500 12500 18000 25000 40000 40000 25000×2
Power Kw 0.6 0.6 0.75 1.5 1.5 3 3 1.5X2
Model FN21 FN30 FN40 FN60-2 FN75-2 FN95-2 FN110-2 FN75X2
Weight Kg 130 160 200 300 420 580 580 420X2

Connecting Pipes

Steam Pipe mm φ19.05 φ28.6 φ28.6 2-φ28.6 2-φ28.6 2-φ34.9 2-φ34.9 2-φ41.3
Liquid Pipe mm φ12.7 φ15.88 φ15.88 2-φ15.88 2-φ15.88 2-φ15.88 2-φ22.2 2-φ22.2
