Cold Storage Dehumidifier CFZ-3.2BDL

Low temperature dehumidifier (CFZ-3.2BDL) is one of the most popular refrigeration units produced by our company. This model is specifically designed to provide effective dehumidification in environments where low temperatures are required, making it ideal for dehumidifier in a cold room, food processing plants, pharmaceutical and chemical manufacturing facilities, and other industrial settings.

Dehumidifying Capacity:3.2kg/h —— 20kg/h
Power: 380V-3P-50Hz
Rated Input Current: 7.1A——16A
Rated Input Power:1.4kW——8.4kW
Working Temperature:0~10℃
Circulating Air Flow:850m³/h——5200m³/h
Drainage Mode:Hose Continuous Drainage
Defrost Method:Thermal Fluoride Defrosting
Application Area (3 Meters High):160——1200m³
Send Inquiry

Product Introduction Technical Parameter

1712734969439

Cold Storage Dehumidifier

One of the key advantages of the CFZ-3.2BDL is its ability to operate effectively in temperatures as low as(0°C to 10°C), while still providing high-capacity humidity removal. This capability is due to the unit's unique design, which includes a powerful compressor, high-efficiency heat exchanger, and a sophisticated control system that optimizes performance, even under extreme conditions.



Another advantage of the CFZ-3.2BDL is its compact size and portability, which make it easy to move between different locations or integrate into existing refrigeration systems. Additionally, the unit is designed for straightforward installation and maintenance, with convenient access to all key components, including the filter, condenser, and evaporator.



Overall, the CFZ-32BDL dehumidifier for freezing temperatures is an exceptional choice for any facility that requires effective humidity control in a cold environment. Its advanced features, high performance, and ease of use make it the perfect solution for a wide range of industrial applications.



Feature and Advantage


1. The unit has good adaptability to low-temperature environment operation, and is specially used for dehumidification in low-temperature refrigerators and low-temperature environments (0°C to 10°C);

2. The self-developed special control program can completely remove the frost layer on the surface of the evaporator in a relatively short period of time, and the unit runs stably and reliably;

3. Low-temperature resistant unit, when the control system detects that defrosting is required, the unit automatically switches the operation mode, enabling hot fluorinated frost, and when the control system detects that defrosting is completed, the unit automatically enters the dehumidification operation;

4. The unit is equipped with an anti-icing device for the water spray tray, which can effectively ensure the normal operation of the unit.



Product Accessories

1712732907494

Application

1 3
1 8
1 11
1 4
1 1
1 2
1 12
1 9

Send Inquiry

We have an advanced technical team and a professional after-sales department that can provide 24-hrs online consulting services.

We warmly welcome you to wholesale customized chiller made in China here from our factory.

Pls contact us for more details.

Hot Tags: cold storage dehumidifier cfz-3.2bdl, China cold storage dehumidifier cfz-3.2bdl manufacturers, suppliers, factory, Dehumidifier for cold temperatures, Dehumidifier that works in low temperatures, cold storage humidity control, Low temperature dehumidifier, Low temperature dehumidifier for basement, low temp dehumidifier

Model No.

CFZ-3.2BDL

CFZ-7BDL

CFZ-10BDL

CFZ-15BDL

CFZ-20BDL

Dehumidifying Capacity

3.2kg/h

7kg/h

10kg/h

15kg/h

20kg/h

Power

220V~50Hz

380V~50Hz

380V~50Hz

380V~50Hz

380V~50Hz

Rated Input Current

7.1A

6.9A

7.8A

13A

16A

Rated Input Power

1.4kW

2.82kW

4.2kW

5.6kW

8.4kW

Working Temperature

0~10℃

0~10℃

0~10℃

0~10℃

0~10℃

Circulating Air Flow

850m³/h

1650m³/h

2600m³/h

3900m³/h

5200m³/h

Drainage Mode

Hose Continuous Drainage

Overall Size (mm)

495(W) × 485(D) × 1055(H)

605(W) × 405(D) × 1605(H)

775(W) × 470(D) × 1705(H)

1190(W) × 450(D) × 1740(H)

1190(W) × 450(D) × 1740(H)

Net Weight

55kg

70kg

160kg

240kg

300kg

Defrost Method

Thermal Fluoride Defrosting

Application Area (3 meters high)

160~180m³

240~320m³

350~500m³

600~820m³

900~1200m³

Refrigerant

(R22) 0.9kg

(R22) 1.5kg

(R22) 1.8kg

(R22) 3kg

(R22) 3.6kg

Running Noise

≤50dB

≤60dB

≤65dB

≤65dB

≤70dB
