Ceiling Mounted Dehumidifier

Commercial ceiling mounted dehumidifiers(DDH-858B/8156B/DCFZ-15) compact and discreet design are their one of advantages. As their name suggests, these units are designed to be installed in suspended ceilings, providing effective humidity control without taking up valuable floor space. Strong dehumidification capacity, the ceiling mounted dehumidification can reach 15kg/h.This makes them ideal for use in areas such as factory, hotels, warehouse, and underground garage.

Refrigerant:R22
Dehumidifying Capacity:58L/D——360L/D
Power:220V~50Hz(380V~50Hz)
Rated Input Current:4.5A——13A
Rated Input Power:0.95kW——5.6kW
Working Temperature:5~38℃
Circulating Air Flow:500m³/h——4300m³/h
Drainage Mode:Hose Continuous Drainage
Brand:Feizhong
Send Inquiry

Product Introduction Technical Parameter




Commercial Ceiling Mounted Dehumidifiers

Commercial ceiling mounted dehumidifiers(DDH-858B/8156B/DCFZ-15) compact and discreet design are their one of advantages. As their name suggests, these units are designed to be installed in suspended ceilings, providing effective humidity control without taking up valuable floor space. Strong dehumidification capacity, the ceiling mounted dehumidification can reach 15kg/h.This makes them ideal for use in areas such as factory, hotels, warehouse, and underground garage.



In addition to their space-saving design, our suspended ceiling dehumidifiers are also highly efficient and effective at removing excess moisture from the air. They use advanced technology to remove humidity quickly and efficiently, helping to prevent the growth of mold and other harmful microorganisms. This can help to improve air quality and create a more comfortable and healthy indoor environment.

Another key advantage of our suspended dehumidifier ceiling mount is their ease of use and maintenance. They are designed to be simple to install, operate, and maintain, with intuitive controls and durable components that ensure reliable and long-lasting performance.



Overall,the above ceiling dehumidifiers are high-quality, efficient, and versatile units that are ideal for a wide range of applications. Whether you need to control humidity in a commercial or industrial setting, our suspended ceiling dehumidifiers are an excellent choice that will provide reliable and effective performance for years to come.





Feature and Advantage

1: Save floor space, dynamic display of humidity

2: 1% humidity precise control

3: Automatic frost function, 5 ℃ low temperature can be used

4: Compressor automatic delay protection for 3 minutes

5: Mute, time-saving, worry-free, and power-saving

6: Timing shutdown function

7: Fault indication function (code display)

2



Application

1 1
1 2
1 3
1 4
1 5
1 6
1 10
1 12

Send Inquiry

We have an advanced technical team and a professional after-sales department that can provide 24-hrs online consulting services.

We warmly welcome you to wholesale customized chiller made in China here from our factory.

Pls contact us for more details.

Hot Tags: ceiling mounted dehumidifier, China ceiling mounted dehumidifier manufacturers, suppliers, factory, Above ceiling dehumidifier, dehumidifier ceiling mount, above ceiling dehumidifiers, In ceiling dehumidifier, Ceiling ducted dehumidifier

Model No.

DDH-858B

DDH-8156B

DCFZ-15

Dehumidifying Capacity

58L/D

156L/D

360L/D

Power

220V~50Hz

220V~50Hz

380V~50Hz

Rated Input Current

4.5A

10.2A

13A

Rated Input Power

0.95kW

2kW

5.6kW

Working Temperature

5~38℃

5~38℃

5~38℃

Circulating Air Flow

500m³/h

1800m³/h

4300m³/h

Drainage Mode

Hose Continuous Drainage

Overall Size(mm)

670(W)×585(D)×375(H)

800(W)×650(D)×465(H)

1300(W)×1200(D)×700(H)

Net Weight

30kg

70kg

150kg

Compressor Protection

Compressor 3 Minutes Automatic Delay Protection

Application Area  (3 meters high)

60~110m²

150~200m²

300~600m²

Refrigerant

(R22)0.6kg

(R22)1.25kg

(R22)1.5*2kg

Running Noise

≤45dB

≤50dB

≤65dB

Humidity Range

30%~95%, ±5%

30%~95%, ±5%

30%~95%, ±5%

Test Working Condition

T=30℃; RH=80%

T=30℃; RH=80%

T=30℃; RH=80%
